Medical Endoscope Washer-Disinfector | Automatic Endoscope Cleaning & Disinfection Machine

Medical Endoscope Washer-Disinfector – Automatic Endoscope Cleaning & Disinfection Machine

The Medical Endoscope Washer-Disinfector is a high-performance, automatic cleaning and disinfection machine designed for hospitals and medical facilities to ensure the safe and effective reprocessing of endoscopes. Engineered with advanced features, it offers reliable hygiene control, efficient operation, and ease of use.

🔧 Key Features:

1. All-in-One Washing & Disinfection – Thorough internal and external cleaning with automatic disinfection for superior hygiene.

2. Internal Channel Booster Pump – Enhances the cleaning performance by thoroughly flushing internal channels.

3. External Water Filtration – Filters incoming water for improved rinsing and equipment protection.

4. Sterile Water Rinse – Final rinse with sterile water to ensure residue-free instruments.

5. Integrated Drying Function – Built-in drying system reduces manual handling and prevents contamination.

📐 Specifications:

• Product Name: Medical Endoscope Washer-Disinfector / Automatic Washer Machine

• Disinfectant Tank Capacity: 12 L

• Enzyme Storage Tank Capacity: 1.7 L

• Alcohol Storage Tank Capacity: 1.7 L

• Disinfectant Dosage: 10 L

• Enzyme & Alcohol Dosage: Adjustable as per user needs; automatically injected during operation

• Leak Detection: Continuous monitoring with real-time alarms on air leakage

• Disinfection Count: Microcomputer tracks and displays total disinfection cycles

• Disinfection Time:

  • Glutaraldehyde: ≥43℃ for ≥10 mins / ≥23℃ for ≥18 mins

  • Ortho-phthalaldehyde: ≥23℃ for ≥10 mins

  • Peroxyacetic Acid & Electrolyzed Water: Room temp, ≥10 mins

• Temperature Control & Safety: Auto shutdown and alarms for faults or insufficient temperature/disinfectant

• Solution Handling: Automatic solution absorption and drainage

• Chamber Cover (Optional Electric Control): Reduces cross-contamination risks

• Noise Level: ≤70 dB (during blow-drying)

• Ambient Temperature Range: 5℃–40℃

• Disinfection Efficacy: Bacillus atrophaeus Nakamura log10 reduction ≥3.00

• Self-Disinfection Cycle: Prevents recontamination

• Optional Print Function: Automatically prints disinfection reports

📏 Dimensions:

• Compact Machine Size:
  Width ≤ 445mm | Depth ≤ 655mm | Height ≤ 930mm

• Spacious Chamber Size:
  Length ≥ 505mm | Width ≥ 385mm | Depth: customizable

Ideal for clinical environments requiring rigorous infection control, this washer-disinfector offers automation, precision, and peace of mind for endoscope processing.
