Achieve superior precision and stability with this advanced Double Beam UV/VIS Spectrophotometer, designed for demanding laboratory applications across the ultraviolet and visible spectrum (190–1100 nm). Its innovative optical system, high-grade blazed holographic grating, and mono-chromator design ensure exceptional wavelength accuracy and minimal stray light—ideal for quantitative and qualitative analysis.
Engineered for long-term durability, the integrated structure includes a suspension-style optical system mounted on a robust 16mm aerospace-grade aluminum base. This significantly reduces interference from mechanical deformation and external vibration, ensuring consistent performance over time.
Equipped with premium components, including precisely aligned silicon photodiodes, deuterium and tungsten halogen lamps, this system delivers high-precision results across the entire UV/VIS range. A large 6-inch (320×240 dots) LCD screen provides clear data visualization and intuitive operation.
Key Features:
-
Dual Beam Optical System: Ensures superior resolution, enhanced stability, reduced stray light, and accurate, repeatable measurements.
-
Multiple Measurement Modes: Supports photometric analysis, quantitative testing, spectrum scanning, kinetic studies, DNA/protein analysis, and multi-wavelength testing.
-
High-Performance Optical Base: The optical path is mounted on a thick aluminum base, optimizing mechanical stability.
-
Enhanced Software Integration: Bundled with professional PC software supporting GLP/GMP compliance, user access control, audit trails, and printable reports.
-
Expandable Configuration: Compatible with a range of accessories, including an 8-cell automatic sample holder, micro cuvette holders, thermostatic autosamplers, and integrating spheres.
-
Real-Time Clock: Automatically timestamps results for traceability.
-
Online Firmware Updates: Internet connectivity allows software upgrades for stand-alone models.
Technical Specifications:
-
Optical System: Double Beam with 1200 lines/mm grating
-
Wavelength Range: 190–1100 nm
-
Bandwidth:
-
UV-8000: 1.8 nm
-
UV-8000A: 1.0 nm
-
UV-8000S: 0.5/1.0/2.0/4.0 nm selectable
-
-
Wavelength Accuracy: ±0.1 nm @ 656.1 nm; ±0.3 nm across full range
-
Wavelength Repeatability: ±0.2 nm
-
Photometric Accuracy: ±0.2%T
-
Photometric Repeatability: ±0.1%T
-
Photometric Range: -0.3–3A, 0–200%T, 0–9999C
-
Stability: ≤0.0005A/h
-
Stray Light: ≤0.05% @ 220 nm & 360 nm
-
Baseline Flatness: ±0.001A
-
Noise: ≤0.001A @ 500 nm
-
Display: 6-inch LCD (320×240 Dots Matrix)
-
Data Output Ports: USB, Parallel
-
Lamps: Deuterium and Tungsten Halogen
-
Detector: Silicon Photodiode
-
Power Requirements: AC 220V/50Hz or 110V/60Hz
-
Dimensions: 625 × 430 × 206 mm
-
Packing Dimensions: 840 × 640 × 440 mm
